Bicycle Fork Mount

The Loaded Bikes Bicycle Fork Mount provides a versatile way to securely transport your bikes in transit and has been designed to give you maximum flexibility. The Fork Mount’s integrated off-set allows the Bicycle Fork Mount to be positioned at 180 degrees from one another, with finer rotational adjustment to enable easy staggering of bikes to minimise clashing of handlebars. The Fork Mount’s single stud locator, compatible with both our low profile flush and surface mounted rail systems, slides easily along the rails to your chosen fixing position and fastens in place by aluminium thumb nut so you can closely position the bikes in whatever configuration you choose. Each Fork Mount comes with a single stud locator, thumb nut and one set of adaptors compatible with a variety of thru-axle and quick-release fork types. Adaptors are available in the following options:

• 5x100mm Quick Release Classic
• 9x100mm Quick Release
• 12x100mm Road & Cyclocross
• 12x110mm Road & Gravel E-Bike Boost
• 15x100mm Non-Boost
• 15x110mm Boost
• 15x110mm Boost Lyric Torque Cap
• 20x110mm Down Hill Boost
• 15x150mm Fat Bike

There is also the option to purchase a bespoke fork mount adaptor if any of the above are not compatible with your bike's forks. Additional pairs of adaptors available to purchase separately if required. If you're not sure what adaptors you need for your bike/s, you may find our What Fork Mount Adaptors do I need for my bike? article helpful.

Fork Mount L-Track Rail Compatibility:

• Compatible with our low profile flush and surface mounted rails
• Compatible with Mercedes OEM flush rails
• Compatible with Genuine Unwin flush and surface mounted rails
• Compatible with Mobiframe Rails
• Compatible with Allsafe L-Track Rails
• Can be made to be compatible with Reimo Rails

Product information:

• UK Designed and Manufactured from high strength aerospace grade aluminium
• 5 axis CNC billet machined
• Design optimised with Finite Element Analysis to maximise structural stiffness and minimise weight.
• Analytically crash tested in ANSYS
• FEA tested to withstand up to 20G of force with a bike up to 27 kg in weight
• Integrated off-set
• Single stud location to enable 360° rotation of Fork Mount (in 22.5° increments)
• Available with a full range of spacers to accommodate a variety of fork types

**FLUSH/SURFACE MOUNTED RAILS NOT INCLUDED**
